HighPoint RocketRAID 2680 SGL

Úvod Řadiče SAS/SATA SAS/SATA II (3Gb/s)HighPoint RocketRAID 2680 SGL

HighPoint RocketRAID 2680 SGL

Zboží je bazarové - otestované 100% funkční



HighPoint RocketRAID 2680 SGL PCI-Express x4 Low Profile SATA / SAS RAID Controller Card

  • RAID 0/1/5/10/50 JBOD
  • 2 x SFF-8087 mini-SAS Internal Connectors
  • Up to 3Gb/s
Výrobce: HighPoint
Kód: 2680

Dostupnost: Prodáno
Počet ks: 0 ks
2 990,- Kč1 850,- Kč

HighPoint RocketRAID 2680 SGL

HighPoint RocketRAID 2680 SGL


Stránky výrobce



The RocketRAID 2680 is a high-performance SAS RAID solution, delivering reliability to demanding data-intensive applications such as tiered storage environments (disk-to-disk), security and surveillance, video editing, and digital content creation. Support for both SAS and SATA 3Gb/s drives on the same controller maintains configuration optimization for performance based on the characteristics of SAS and SATA drives available today.

newegg SAS 3Gb/s Compliant The HighPoint RocketRAID 2680 supports up to 8 SAS 3Gbps or SATA 3Gbps devices for enhanced flexibility and speed.newegg RAID Support The HighPoint RocketRAID 2680 supports multi-level RAID configuration including RAID 0, 1, 5, 10, 50 and JBOD for better performance, enhanced data security and flexible capacity upgrades.newegg PCI Express x4 Interface The PCI Express x4 interface provides substantial bandwidth and full-duplex operation for bottleneck-free performance.
newegg HighPoint RAID Management HighPoint RAID Management HighPoint RAID Management software offers a user friendly interface to create, manage and maintain your storage solutions. Email notification and remote are some of the advance features that the RAID Management software has to offer.
newegg Comprehensive OS Support HighPoint offers the broadest range of support for all major operating systems to ensure OS and hardware server compatibility. Drivers are available for all major operating systems, including Windows , Linux, Mac OS X and FreeBSD.

HighPoint Technologies, Inc. RocketRAID 2680 SGL
Model
Brand
HighPoint
Model
RocketRAID 2680 SGL
Form Factor
Low Profile
Specifications
Type
SATA / SAS
Internal Connectors
2 x SFF-8087 mini-SAS
Interface
PCI-Express x4
Transfer Rate
Up to 3Gb/s
RAID
RAID 0/1/5/10/50 JBOD
Dimensions
3.12" x 2.55"
Features
Features
RAID Controller: Marvell 88SE6485

Maintenance and Management Settings:
RAID Array Roaming
Unplug/Remove RAID array
Hot key (ctrl-h) boot-up RAID manager via BIOS
Firmware update while running the Operating System
Verify RAID Array for Bad Sectors and Parity Check
Task Scheduler
Automatic RAID rebuild
Automatic drive (insert / removal) detection
Hot Spare Disk
Staggered Drive Spinup
Rebuild Priority (Low - Highest)
Spin Down Idle Mode
Hot Swap and Hot plug
Bad sector repair and remapping to reduce dropped drives
Multiple RAID array
Multiple Logical Drive
64bit LBA support greater than 2TB per volume

RAID Monitoring Tools:
SMTP for email notification
Alarm / Buzzer alerts for drive failure
SES-2 enclosure management (Failed, SMART (SHI))
Enclosure management support I2C
Hard Drive LED indicators (Activity and Failed)
SHI (Storage Health Inspector - Drive analysis from S.M.A.R.T)
Event Log

RAID Management Suite:
Command Line Interface (CLI)
Web browser-base RAID management software
API.
Raid Level: 0, 1, 10, 5, 50, JBOD
Celkový počet portu: 8
Počet internich portu: 8
Připojeni k PC: PCI-Express x4
